The HxR series regulators are high performance voltage regulating components targeted at performance-critical audio applications. Key performance parameters exceed that of industry-standard integrated circuits by several orders of magnitude. Kelvin sense connections provide point-of-load (local) regulation without requiring physical proximity.
The HxR12 is a 12V regulator.
APPLICATIONS:
- Preamplifiers and buffers
- RIAA input stages
- Playback head amplifiers
- Performance upgrade for existing products
GENERAL FEATURES:
- Ultra-low noice
- Wide bandwidth
- Excellent ripple rejection
- Low, load-independend output impedance
- Kelvin sense connections
- Size and pin compatible with TO-220 style regulators
ELECTRICAL FEATURES:
- Max. input voltage: 60V
- Output voltage: 12V
- Max. output current: 100mA
- Power dissipation: 1W
- Output impedance: 50mOhm
- Ripple rejection: 110dB
- Output Noise Voltage: 290nV
MECHANICAL FEATURES:
- Weight: 5g
- Dimensions: 25mm x 15mm
