- Large surround dome for increased acoustic output
- Dual balanced compression chamber for improved dynamics
- Dual copper caps for absolute minimum voice coil inductance and minimum phase shift
- Two part aluminium faceplate with integrated mechanical decoupling
- Saturation controlled motor system with T-shaped pole piece for lower distortion
- Non-reflective cast aluminium chamber with optimized damping for improved dynamics
- Flow optimized vented pole piece for optimum coupling to rear chamber
- CCAW voice coil for low moving mass
- Long life silver lead wires
- Low resonance frequency for extended range
| Titel | Type | Størrelse | Download |
|---|---|---|---|
| SATORI-TW29D-B.pdf | 608.18KB | Download |
