- Aluminium/Ceramic Dome
- Phase optimized diaphragm design for coherent high frequency radiation
- Copper cap for reduced voice coil inductance and minimum phase shift
- Saturation controlled motor system for low distortion
- Non-reflective rear chamber with optimized damping for improved dynamics
- Flow optimized vented pole piece for optimum coupling to rear chamber
- CCAW voice coil for low moving mass
- Long life silver lead wires
- Low resonance frequency
| Titel | Type | Størrelse | Download |
|---|---|---|---|
| SB26CDC-C000-4.pdf | 543.34KB | Download |
