- Coated non-resonant soft dome
- Powerful neodymium motor system
- Tuned closed-end transmission line chamber
- Dynamic dome stabilizer and flow resistor
- Machined aluminium faceplate
- Vented coil former
- Braided long-life silver litz wires
- - - - - - -
Specs
- Nominal Impedance 6 Ω
- DC resistance, Re 5.3 Ω
- Voice coil inductance, Le 0.14 mH
- Effective piston area, Sd 32 cm2
- Voice coil diameter 60.5 mm
- Voice coil height 4.3 mm
- Air gap height 3 mm
- Linear coil travel,Xmax ±0.5 mm
- Magnetic flux density 1.28 T
- Magnet weight 0.06 kg
- Net weight 0.58 kg
- Free air resonance, Fs 400 Hz
- Sensitivity (2.83V/1m) 95 dB
- Mechanical Q-factor, Qms N/A
- Electrical Q-factor, Qes N/A
- Total Q-factor, Qts N/A
- Moving mass incl. air,Mms 2.0 g
- Force factor, Bl 7.2 Tm
- Equivalent volume, Vas – liters
- Compliance, Cms – mm/N
- Mechanical loss, Rms – kg/s
- Rated power handling 120 W
| Størrelse (Tommer): | 2,5 |
| Ohm: | 6 |
| Titel | Type | Størrelse | Download |
|---|---|---|---|
| SB-Acoustics-2.5in-SATORI-MD60N-6.pdf | 565.23KB | Download |
