- Advanced TeXtreme® cone for improved piston operation
- Large optimized motor system with under-cut pole piece and dual shorting rings
- Vented aerodynamic cast aluminum chassis for optimum strength and low compression.
- Soft low damping rubber surround for optimum transient response
- Linear symmetric suspension design for improved dynamic performance
- Non-conducting fibre glass voice coil former for minimum damping
- Long life silver lead wires attached 180° apart for improved stability
- Vented pole piece for reduced compression
- Low piston to chassis diameter ratio
- Gasket and bolt hole protrusions for reduced coupling to speaker cabinet.
| Titel | Type | Størrelse | Download |
|---|---|---|---|
| 9.5in-SATORI-WO24TX-8.pdf | 1.84MB | Download |
